CALLIES COMPSTAR XTREME POWER ADDER FORGED CONNECTING RODS FOR GEN 5 LT1/L86/L87 5.3L/6.2L ENGINES
NOTE: 6.125" length requires the use of aftermarket pistons. NOT compatible with OEM GM pistons.
Connecting Rod Style: FORGED H-BEAM
Rod Length: 6.125"
Piston Pin Size: .927"
Rod Journal Size: 2.100"
Rod Bolts: ARP 2000
These highly anticipated LS 'Xtreme' rods are designed specifically for boosted applications who are looking to retain all the same proven premium forged 4340 material, ARP fasteners & quality workmanship that you would expect from a Callies product BUT with the addition of added strength of thickened flanges of the H-beams. Callies have engineered these rods to remove the non-essential weight (taken from the beam) to help reduce & keep the overall weight of these rods in order.
The LS 'Xtreme' rods are designed for engines planning on seeing anywhere in between 1,200 to 1,800 horsepower mark.
NOTE: Connecting rods only. Bearings must be purchased separately.
